Description
The CardioTouch 3000 is a premium quality interpretive 12 channel electrocardiogram (ECG / EKG)
machine that does not compromise on performance. Suitable for use in private practice, the ER, or
hospitals. The CardioTouch 3000 is designed for maximum ease of use and convenience.
Specification:
Simultaneous 12 Channel Electrocardiograph (ECG/EKG) with a Touch of Succinct Report Simple, Intuitive yet Accurate
Easy of use interface with 4.3” LCD TFT Touch screen with rotary knob button
One button “AUTO” operation from acquisition to data storage, print-out & data transfer in 3 sec’
Convenient A4 print-out for 12CH ECG with a single page report
8,000 sampling rate per second
User-Friendly Interface & Diagnosis
Quick guide indication at printer cover for easy operation recognition
Rotary knob push button for controlling all menus
Thermal A4 paper compatible with grid printing mode
120 types of interpretation algorithm integrated
Rechargeable Li-ion battery for 3hr operation / 200 pages printout
Network & Data management
Wired, wireless connectivity with easy DHCP interface
BMS-Plus connection to PC for data transfer to HIS (PACS/EMR) with various file format conversion JPEG, BMP, XML, PDF.
| Feature | Specification |
|---|---|
| ECG Leads | Simultaneous 10 Leads Resting ECG (12 channel) |
| Dimension | 290 (W) x 300 (D) x 97.5 (H) mm |
| Approximately 3.5 kg (Main Body) | |
| Recording Channel | 3CH+1RHY, 3CH+3RHY, 6CH+1RHY, 12CH, 1CH Long Time (1min) and Beat Report |
| Sensitivity | 2.5, 5, 10, 20, Auto (I~aVF: 10, V1~V6: 5) mm/mV |
| Printing Speed | 5, 12.5, 25, 50, 100mm/sec |
| Sampling Rate | Analysis Sampling Rate: 500 sample/sec Digital Sampling Rate: 8,000 sample/sec |
| Filters | AC (50/60Hz, -20dB or better), Muscle (25~35Hz, -3dB or better), Base Line Drift (off, 0.05, 0.1, 0.2Hz, -3dB or better), Low Pass Filter (off, 40Hz, 100Hz, 150Hz) |
| Display | 272 x 480 Pixel Resolution, 4.3” Color TFT Display 12 Channels Preview, ID, HR, Gain, Speed, Power Status |
| Export file format | ECG, XML, PDF, JPEG, MFER |
| User Interface | Touch Screen, Rotary Push-knob |
| Recorder | Thermal Print Head, Roll Paper Report Paper – Width: A4/Letter – 215mm (8.5”) – Length: A4 – 297mm (11.7”) Letter – 279mm (11”) Resolution: 8dot/mm (0.125mm pitch) |
| Patient data | ID, Name, Age, Gender, Height, Weight |
| Basic Measurement | Heart Rate: 30~300bpm (±3bpm) PR, QRS, QT/QTc, P-R-T axis |
| ECG Data Storage | Internal Storage for 200 ECGs: Built- in Memory External memory available |
| Electrical | Internal Noise: 20uV(p-p)max |
| Input Impedance: More than 50MΩ | |
| Input Voltage range: ±5mV | |
| CMRR: Greater than 105dB | |
| DC offset Voltage: ≥ ±400mV | |
| Patient Leakage Current: < 10uA | |
| Frequency Response: 0.05~150 with in –3dB | |
| Isolated, Defibrillation and ESU Protected | |
| Signal Quality Control | Pacemaker Pulse Detection Lead Fault Detection, Signal Saturation Detection |
| Power | Input: 100-240Vac, 1.5-0.75A, 50-60Hz, Output: 15Vdc, 4.2A |
| Battery type | Replaceable and Rechargeable, Lithium ion, 11.1V, 2600mA |
| Battery Capacity | 6 hours of normal use (without recording,200 ECGs) with 12 channel Battery charge time is 3 hours. |
| Communication | LAN, USB, WIFI (option) |
| Safety Conformity | Class I, Type CF Defibrillation-proof applied Part |
| Environment | Operating Temperature: 5~40°C Operating Humidity: 10~90%RH Atmospheric Pressure: 70~106KPa |
| Standard Accessory | Power Cord – 1 ea Patient Cable – 1 ea ECG clips – 1 set Disposable Electrodes – 1 pouch Chart paper – 1 ea Operation manual – 1 ea Rechargeable battery – 1 ea |
